Stamping Die Design Solid Edge Training
Ø 20” Flywheel Bracket .25” Thick CRS
Pierce, Coin, Flip to Pierce 4400 Ton Press (2)
Blank, Pre-Form, Form 4400 Ton Press (1)
9660 - Small Progressive Die.
4621 Strip Layout
4621 - Progressive Die
2nd Half Dies on Table
11697 - Progressive Die .078 T x Ø 17” 1075 40-50Rc

Portfolio of Designs

8 Station Progressive Die .19” HSLA Shaved Serrations
Montage of Parts and Strips
Small Part Stamping .007” Thick Nickel Cobalt
Large Part Stamping .22Thick PLT Steel x 4’ Lg
9968 - Support, Rasp Bar 3/16” HSLA 80 Grade
9968 - 12 Station Prog Die w/M12 Strux Nut Insert
3525 - Connector Terminal 1/32” Half Hard Brass
3525 - Progressive Die (LWR) #4-40 & #6-32 In-Die Tapping
